made in cast iron, with a capacity of up to 4300Nm

ROBUS-25-60 in-line helical gearboxes

made in cast iron, with a capacity of up to 4300Nm

ROBUS Type max Nm
(4 poli)
A2 63-71-80 165
25 63-71-80-90-100-112 350
30 71-80-90-100-112 450
35 71-80-90-100-112 700
40 80-90-100-112-132 1100
50 90-100-112-132-160-180 2500
60 100-112-132-160-180-200 4300

ROBUS is the new range of in-line helical reducers of motive, made in cast iron, with a capacity of up to 4300Nm.

uniquely contoured, rigid, precise, monobloc, cast iron body, base and flange ensure extreme robustness.

a large top cover in light weight aluminium alloy facilitates the inspection

modular design with detachable output flange and foot base allows easy and quick conversion between foot and flange mounting

Various detachable foot bases in solid cast iron make Robus interchangeable with any other gearbox brand

except version a, all Robus sizes have a screw-on lifting eyebolt

Easy to examine and maintan. Minimum maintenance requirement. All sizes are supplied with long-life synthetic oil.

IEC flange and hollow shaft. Choice of hollow input flanges permits direct mounting of any standard motor

Unique construction of Robus makes it possible to mount any size in any position. This flexibility is achieved by: + ZZ autolubricating bearings on input and output shaft

6 interchangeable plugs, including one breather plug and a level plug Please note that the vent plug also allows you to reduce the internal pressure on seals, and thus increases the efficiency of the gearbox

+ mechanical parts locked in their positions by snap rings and spacers.This also ensures better absorbtion of axial thrust and prolongs the life of bearings
