made with die-casting aluminium housing from size 25 up to 90, and in cast iron from size 110

BOX worm gearboxes

Buy online

The new patented “BOX” series of worm gear units is made with die-casting aluminium housing from size 25 up to 90, and in cast iron from size 110.

The whole BOX series can be mounted in any position with no need of specifications in the order

BOX motor type max Nm
(4 poles)
25 56 13
30 56-63 19
40 63-71 39
50 63-71-80 74
63 71-80-90 135
75 80-90-100-112 205
90 80-90-100-112 360
110 90-100-112-132 675
130 90-100-112-132 850
150 100-112-132-160 1200

From type BOX75 upwards, 2 tapered roller bearings are mounted on the the tapered shaft, which improves the mechanism and mechanical resistance to axial loads given by by the bevel gear. In addition, the combination of 2 tapered roller bearings with 2 nilos (mounted on sizes 75 upwards to keep the lubrication, grease, inside the bearings even when they are not touched by the oil bath), or, alternatively, special RS shields on such tapered bearings, allows the entire BOX range, from size 25 to size 150, to be mounted in the V5 and V6 positions without the need for additional interventions.

The BOX series endless gearboxes are constructed with a die-cast aluminium housing up to size 90 and cast iron from size 110 upwards. The structure has been designed using three-dimensional parametric SW CAD and with the help of heat dissipation capacity and structural deformation/rupture resistance analysis programs under the effect of operating torque and external loads, with positive results in terms of sealing surfaces.

2 protected bearings on the output output shaft allow mounting in position B6 or B7 in series. In conclusion, the entire range can be assembly in any position without further specification in the order form

The special shape of the carcass has been designed to optimize water drainage during washing and avoid stagnation

Gearboxes up to type 90 are supplied by Motive lubricated for life with a synthetic oil, while from the type 110 and above, mineral oil is used. A vent plug is supplied as standard. The blind and level plugs are fitted by Motive in all possible Motive in all possible positions, facilitating customer stock management for the customer, who can decide at a moment's notice position at the last moment by positioning the plug before before commissioning.

To increase soundproofing, efficiency and service life the worm is case-hardened, hardened and the teeth ground, the worm gear helical crown is made of a special bronze alloy ZCuSn12 bronze alloy. The worm wheel's standard hollow shaft is made of spheroidal cast iron, an alloy that offers superior performance to gray cast iron, and is also suitable for intensive use

A coat of epoxy paint paint cancels out the effects of surface porosity of aluminum surface porosity of aluminum oxidation.

The mounting faces are milled to ensure perfect flatness for mounting.

2 plastic caps at the outlet protect the gearbox during transport and storage and protect the user from accidental contact with moving moving parts.
